Attach the device to an emergency power off (EPO) system so that power can be turned off in an emergency situation. Green mode bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. High frequency design reduces or eliminates bulky transformers resulting in lighter units for ease of handling. Energy meter provides actual kilowatt hours of usage for energy conscious users. Intuitive LCD interface provides clear and accurate information with the ability to configure the UPS locally with easy to use navigation keys. UPS recognizes when external battery packs are attached and automatically adjusts runtime. Multiple outlet groups may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on / off and non-critical load shedding.
- EPO
Attach the device to an emergency power off (EPO) system so that power can be turned off in an emergency situation. - Green mode
Green mode bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. - High frequency design
Reduces or eliminates bulky transformers resulting in lighter units for ease of handling. - Energy meter
Provides actual kilowatt hours of usage for energy conscious users. - Intuitive LCD interface
Provides clear and accurate information with the ability to configure the UPS locally with easy to use navigation keys. - Auto recognition of external batteries
UPS recognizes when external battery packs are attached and automatically adjusts runtime. - Multiple switched outlet groups
Multiple outlet groups that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on / off and non-critical load shedding. - Pure sine wave output on battery
Simulates utility power to provide a high degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics. - Scalable run time
Scalable run time allows additional run time to be quickly added as needed. - Cold-start capable
Provides temporary battery power when the utility power is out. - Plug-and-Play external batteries
Ensure clean, uninterrupted power to the loads when adding extra runtime to the UPS. - Rack / tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment. - SmartSlot
Customize UPS capabilities with management cards. - Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature. - Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging. - Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances. - Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power. - Disconnected battery notification
Warns when a battery is not available to provide backup power. - Network manageable
Provides remote power management of the UPS over the network. - Audible alarms
Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition. - Serial connectivity
Provides management of the UPS via a serial port. - Hot-swappable batteries
Ensure clean, uninterrupted power to protected equipment while batteries are being replaced. - Predictive failure notification
Provides early-warning fault analysis ensuring proactive component replacement. - Resettable circuit breakers
Enable a quick recovery from overload events. - Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
General
Device Type
UPS - rack-mountable
Power Device
UPS Technology
Line interactive
Frequency Provided
47 - 63 Hz
Frequency Required
50/60 Hz
Input Connectors
Power IEC 60320 C14
Power Output Connectors Details
8 x power IEC 60320 C13
Output Voltage
AC 230 V ± 5% - 47 - 63 Hz
Power Capacity
600 Watt / 750 VA
Surge Energy Rating
645 Joules
Battery
Run Time (Up To)
14.2 min at full load ¦ 37.8 min at half load
Expansion / Connectivity
Expansion Slots
1 (total) / 1 (free) x SmartSlot
Miscellaneous
Cables Included
Serial cable - external ¦ Power cable - integrated - 1.8 m
Features
Audible alarm, LCD display
Compliant Standards
C-Tick, UL 1449, VDE, EN 50091-2, RoHS Exemption 7b, EN 50091-1
Software / System Requirements
Software Included
APC PowerChute Business Edition
Manufacturer Warranty
Service & Support
Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 95%
Dimensions & Weight
Dimensions & Weight (Shipping)
