be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)
be quiet! Silent Base 601 Orange (BG025)

be quiet! Silent Base 601 Orange (BG025)

be quiet! Silent Base 601 - Tower - extended ATX - no power supply (ATX / PS/2) - orange - USB/Audio

Qty:
View data sheet
Add to comparison list
Category (Gehäuse)
PC Components
Cases
OEM
BG025
EAN
4260052186992
SKU
beqac000064 (118486)
Manufacturer
be quiet!
Type
Mini tower
Color
Orange
Customs tariff number
84733080
UNSPSC
43201601
eClass
19-03-03-01
eClass V7
19-05-06-01
Type
Mini tower
Form factor
ATX
Buildt type
3.5"
Weight
10 kg - 13 kg
Universal interfaces
PS/2

be quiet! Silent Base 601 delivers the perfect combination of maximum silence and an excellent usability for remarkably quiet configurations.

  • Minimize noise and maximize air stream
    The air inlets on the front cater for maximum silence with a constant amount of air permeability. The specially designed vents reroute the inflowing air twice to reduce airborne noise.
  • Extra thick insulation for maximum stability and silence
    The front, top and sides are equipped with extra thick dampening mats, resulting in maximum stability and superb noise dampening capabilities. The decoupled PSU bracket and HDD cages also minimize vibrations.
  • Whisper-quiet operation
    Two pre-installed fans with airflow-optimized fan blades ensure a perfect airflow and solid cooling. The integrated 3-step fan controller caters for up to three fans.
  • Neat interior
    The PSU shroud perfectly covers the cables, PSU and contains a double HDD cage. The cover plates are separately detachable to install a fan on the top.

General
Form Factor
Tower
Max Mainboard Size
Extended ATX
Supported Motherboards
ATX, microATX, Mini-ATX, Extended ATX
Internal Bays Qty
9
Product Material
Steel, ABS plastic
Colour
Orange
Cooling System
Front: 140 x 140 x 25 mm fan x 1 / 1000 rpm / 61.2 cfm / 18.8 dBA / Pure Wing 2 ¦ Rear: 140 x 140 x 25 mm fan x 1 / 1000 rpm / 61.2 cfm / 18.8 dBA / Pure Wing 2 ¦ Front: 120/140 mm fan mount x 2 ¦ Top: 120/140 mm fan mount x 3
CPU Cooler Max Height
185 mm
Video Card Max Length
449 mm
Power Supply Max Length
288 mm
System Cabinet Features
Front dust filter, bottom dust filter, supports 120/140/240/280/360 mm radiator in front panel, supports 120/240/360 mm radiator in top, supports 120/140 mm radiator in top
Expansion / Connectivity
Expansion Bays
6 (total) / 6 (free) x internal - 2.5" ¦ 3 (total) / 3 (free) x internal - 3.5"
Expansion Slots
7
Interfaces
2 x USB 3.0 ¦ 1 x USB 2.0 ¦ 1 x headphones - mini-jack ¦ 1 x microphone - mini-jack
Miscellaneous
Compliant Standards
RoHS
Power
Power Device
No power supply
Specification Compliance
ATX / PS/2
Dimensions & Weight
Width
24 cm
Depth
53.2 cm
Height
48.1 cm
Weight
10.49 kg
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
