Design
Certification
EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC
Management features
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
8
SFP module slots quantity
2
Power connector
DC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
8
Power over Ethernet plus (PoE+) ports quantity
2
Total Power over Ethernet (PoE) budget
78 W
Data transmission
MAC address table
8000 entries
Switching capacity
20 Gbit/s
Forwarding rate
14.88 Mpps
Packet buffer memory
0.512 MB
Network
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology
10BASE-T, 100BASE-T, 1000BASE-T
Cable types supported
Cat5, Cat5e
Multicast features
Power
Power consumption (max)
80.6 W
Security
Access Control List (ACL)
Yes
Operational conditions
Operating temperature (T-T)
-5 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 95 %
Storage relative humidity (H-H)
0 - 95 %
Heat dissipation
373.96 BTU/h
Weight & dimensions
Packaging data
Performance
Mean time between failures (MTBF)
729258 h
