WINDFORCE cooling system The WINDFORCE cooling system features 3 bionic shark fans, alternate spinning, 9 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D Active Fans and Screen Cooling, which together provide high efficiency heat dissipation.
AORUS Bionic Fan Tech The sharks' dermal denticles surrounding their body grant them significant advantages in fluid dynamics. AORUS features Bionic Fan Tech that mimics the scale micro-surfacing and efficiently increases airflow by reducing micro turbulence.
Double ball bearing The double ball bearing structure has better heat endurance and efficiency than sleeve structure.
Large vapor chamber and heat pipe The large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
Alternate spinning Each fan rotates in different direction to the adjacent one. This special mechanism reduces turbulence and increases air pressure by minimizing the offset occurred between airflows.
3D Active Fan The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
Angular fin design The angular and unequal fins height can channel the airflow through the fins and enlarge the contact surface.
Screen Cooling To create more space for airflow to pass through, the heatsink extends over the PCB and therefore increase the ventilation. This Screen Cooling design provides better heat dissipation.
LCD Edge View The LCD monitor displays not only graphics card information, but also various favorite texts, pictures, and GIFs.
RGB Fusion The legendary three-ring lighting provides excellent visual enjoyment.
Dual BIOS The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
Protection metal back plate The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
PCB coating Dust-resistant - shields from dust, insects, dropped screws, drill shavings, and abrasion. Moisture-resistant - prevents unwanted conduction paths and board damage. Corrosion-resistant - protects from salt spray, humidity, and corrosion.
Extreme overclocking The graphics card features excellent power phase design to allow the MOSFETs to operate at lower temperatures and provide a more stable voltage output. Load balancing of each MOSFET can effectively improve the overclocking performance and extend the life of the card.
General
Device Type
Graphics card
Bus Type
PCI Express 4.0
Graphics Engine
NVIDIA GeForce RTX 4070 Ti
Core Clock
2670 MHz
CUDA Cores
7680
Max Resolution
7680 x 4320
Max Monitors Supported
4
Interfaces
3 x DisplayPort ¦ HDMI
API Supported
OpenGL 4.6, DirectX 12 Ultimate
Features
Dual Bios, GIGABYTE WINDFORCE cooling design, RGB fusion, Vapour chamber direct touch technology, Triple Fan Design, Gigabyte Alternate Spinning, Nvidia Studio, 3D Active Fan, NVIDIA Reflex, LCD Edge View, Dual ball Bearing Fans, Nvidia Broadcast, metal backplate, composite copper heat pipes, NVIDIA Ada Lovelace GPU technology, 4th gen Tensor Cores, 3rd gen Ray Tracing Cores, NVIDIA DLSS 3, screen cooling, AORUS Bionic fan technology, PCB dust/moisture/corrosion coating
Memory
Size
12 GB
Technology
GDDR6X SDRAM
Memory Speed
21 Gbps
Bus Width
192-bit
System Requirements
Required Power Supply
750 W
Additional Requirements
16 pin PCI Express power connector
Miscellaneous
Included Accessories
AORUS metal sticker, 16-pin to 3x 8-pin cable adapter, anti-sag bracket
