WINDFORCE cooling system The WINDFORCE cooling system features three bionic shark fans, alternate spinning, 12 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
AORUS Bionic Fan Tech The sharks' dermal denticles surrounding their body grant them significant advantages in fluid dynamics. AORUS features Bionic Fan Tech that mimics the scale micro-surfacing and efficiently increases airflow by reducing micro turbulence.
Double ball bearing The double ball bearing structure has better heat endurance and efficiency than sleeve structure.
Large vapor chamber and heat pipe The large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
Alternate spinning Each fan rotates in different direction to the adjacent one. This special mechanism reduces turbulence and increases air pressure by minimizing the offset occurred between airflows.
3D Active Fan The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
Extreme overclocking The graphics card features excellent power phase design to allow the MOSFETs to operate at lower temperatures and provide a more stable voltage output. Load balancing of each MOSFET can effectively improve the overclocking performance and extend the life of the card.
Friendly PCB design Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
RGB Fusion The three-ring lighting provides excellent visual enjoyment.
Dual BIOS The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
Protection metal back plate The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
General
Device Type
Graphics card
Bus Type
PCI Express 4.0
Graphics Engine
NVIDIA GeForce RTX 4080
Core Clock
2550 MHz
CUDA Cores
9728
Max Resolution
7680 x 4320
Max Monitors Supported
4
Interfaces
3 x DisplayPort ¦ HDMI
API Supported
OpenGL 4.6, DirectX 12 Ultimate
Features
Dual Bios, GIGABYTE WINDFORCE cooling design, Vapor chamber cooling technology, RGB fusion, Gigabyte Alternate Spinning, Nvidia Studio, 3D Active Fan, NVIDIA Reflex, LCD Edge View, Dual ball Bearing Fans, Nvidia Broadcast, metal backplate, NVIDIA Ada Lovelace GPU technology, 4th gen Tensor Cores, 3rd gen Ray Tracing Cores, NVIDIA DLSS 3
Memory
Size
16 GB
Technology
GDDR6X SDRAM
Memory Speed
22.4 Gbps
Bus Width
256-bit
System Requirements
Required Power Supply
850 W
Additional Requirements
16 pin PCI Express power connector
Miscellaneous
Included Accessories
AORUS metal sticker, 16-pin to 3x 8-pin cable adapter, anti-sag bracket
