General
Product Form Factor
Rack-mountable - 1U
Processor / Chipset
CPU
Intel Xeon Silver 4208
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 11 MB
RAM
Installed Size
16 GB / 1 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2400 MHz
Rated Memory Speed
2933 MHz
Slots
16 (Total) / 15 (empty)
Features
Registered, Online Spare Memory, HPE SmartMemory, 6-channel memory architecture
Configuration Features
1 x 16 GB
Hard Drive
Storage Controller
Type
1 x SATA - PCIe 3.0 x4
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Monitor
Graphics Controller
Networking
Ethernet Ports
2 x Gigabit Ethernet
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 1 x HPE iLO - RJ-45 ¦ 4 x USB 3.0 (1 front, 2 rear, 1 internal)
Miscellaneous
Included Accessories
HPE Easy Install Rails, 3 x system fans
Compliant Standards
WEEE, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Environmental Standards
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
