HPE ProLiant DL160 Gen10 - Server - rack-mountable - 1U - 2-way - 1 x Xeon Bronze 3206R / 1.9 GHz - RAM 16 GB - hot-swap 3.5" bay(s) - no HDD - GigE - monitor: none

Qty:

Category (Server & Storage)
Server & Storage
Servers
OEM
P35514-B21
EAN
0190017480947
SKU
129824 (129824)
Manufacturer
HP Enterprise
Type
Server
Customs tariff number
84715000
UNSPSC
43211501
eClass
19-01-01-03
eClass V7
19-01-04-90
Dimensions (Girth)
910 x 600 x 220 (2550)
Processor
Xeon Bronze
Operating systems
Red Hat Linux
Main memory
16GB
Rack height units
1
General
Type
Server
Product Form Factor
Rack-mountable - 1U
Server Scalability
2-way
Hot-Swap Bays Qty
4
Processor / Chipset
CPU
Intel Xeon Bronze 3206R
Clock Speed
1.9 GHz
Number of Cores
8-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Chipset Type
Intel C622
Cache Memory
Installed Size
L3 Cache - 11 MB
Cache Per Processor
11 MB
RAM
Installed Size
16 GB / 1 TB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2133 MHz
Rated Memory Speed
2933 MHz
Form Factor
DIMM 288-pin
Slots
16 (Total) / 15 (empty)
Features
Registered, HPE SmartMemory, 6-channel memory architecture
Configuration Features
1 x 16 GB
Hard Drive
Type
No HDD
Storage Controller
Type
1 x SATA - PCIe 3.0 x4
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i
Channel Qty
14
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Video Interfaces
VGA
Networking
Ethernet Ports
2 x Gigabit Ethernet
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots
1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 1 x HPE iLO - RJ-45 ¦ 4 x USB 3.0 (1 front, 2 rear, 1 internal)
Miscellaneous
Included Accessories
CPU standard heatsink, HPE 1U Easy Install Rails, 3 x standard fans
Compliant Standards
WEEE, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
500 Watt
80 PLUS Certification
80 PLUS Platinum
Environmental Standards
ENERGY STAR Certified
Yes
ENERGY STAR Version
2.1
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width
43.46 cm
Depth
61.49 cm
Height
4.29 cm
Weight
11.65 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
Sound Emission
28.1 dBA
