HPE ProLiant DL380 Gen10 SMB Networking Choice - Server - rack-mountable - 2U - 2-way - 1 x Xeon Gold 5218R / 2.1 GHz - RAM 32 GB - SATA/SAS - hot-swap 2.5" bay(s) - no HDD - 10 GigE - monitor: none

Qty:

Category (Server & Storage)
Server & Storage
Servers
OEM
P24844-B21
EAN
0190017446516
SKU
129886 (129886)
Manufacturer
HP Enterprise
Type
Server
Customs tariff number
84715000
UNSPSC
43211501
eClass
19-01-01-03
eClass V7
19-01-04-90
Processor
Xeon DP
Operating systems
Red Hat Linux
Main memory
32GB
Rack height units
2

The HPE ProLiant DL380 Gen10 server delivers better security, performance and expandability. The HPE ProLiant DL380 Gen10 server is securely designed to reduce costs and complexity. Run everything from the most basic to mission-critical applications and deploy with confidence.

General
Type
Server
Product Form Factor
Rack-mountable - 2U
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localisation
Region: Worldwide
Processor / Chipset
CPU
Intel Xeon Gold 5218R
Clock Speed
2.1 GHz
Max Turbo Speed
4 GHz
Number of Cores
20-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket
FCLGA3647 Socket
Chipset Type
Intel C621
Cache Memory
Installed Size
L3 Cache - 27.5 MB
Cache Per Processor
27.5 MB
RAM
Installed Size
32 GB / 1.5 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2933 MHz
Form Factor
DIMM 288-pin
Slots
24 (Total) / 23 (empty)
Features
Registered, dual rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features
1 x 32 GB
RAM Supported
3 TB Load-Reduced - ECC ¦ 1.5 TB registered - ECC ¦ 192 GB Non-Volatile - ECC ¦ 6 TB - HPE Persistent Memory - Optane DC Persistent
Hard Drive
Type
No HDD
Storage Controller
Type
1 x RAID
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i
Channel Qty
14
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Video Memory
16 MB
Video Interfaces
VGA
Networking
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
HPE 562FLR-SFP+
Data Link Protocol
10 Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 0 (free) x FlexibleLOM
Interfaces
3 x USB 3.0 (1 front, 2 rear) ¦ 1 x VGA ¦ 2 x LAN (10Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 1 x HPE iLO (service port)
Miscellaneous
Included Accessories
Cable management arm, 4 standard fans, SFF Easy install rails
Compliant Standards
WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
800 Watt
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Environmental Standards
ENERGY STAR Certified
Yes
ENERGY STAR Version
3.0
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width
44.55 cm
Depth
73.03 cm
Height
8.74 cm
Weight
14.76 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
