LANCOM Switch GS-3510XP GS3510XP (61849)

Find suitable products

LANCOM GS-3510XP - Switch - L3 Lite - Managed - 4 x 10/100/1000 (PoE+) + 4 x 100/1000/2.5G (PoE+) + 2 x 10 Gigabit SFP+ - rack-mountable - PoE+ (130 W)

View data sheet
Add to comparison list

Category (Netzwerktechnik): Network Equipment
Network Equipment
OEM: 61849
EAN: 4044144618499
SKU: lanne000055 (118975)
Manufacturer: LANCOM
Master carton: 1.0000
Type: Switch
Customs tariff number: 85176200
UNSPSC: 43222612
eClass: 19-03-01-17
eClass V7: 19-17-01-06
Dimensions (Girth): 364 x 84 x 87 (706)
Type: Switch
Amount of ports: 8
Transmission rate: 1Gbps

Description
Features
Specifications
Product safety

The LANCOM GS-3510XP is a reliable basis in smaller network infrastructures for integrating components with high performance requirements, such as Wi-Fi 6 access points. Equipped with 4x 2.5G and 4x 1G Ethernet ports as well as 2x 10G SFP+ uplink ports, it networks up to 10 devices optionally with Power over Ethernet (130W) for installations without additional power supplies or power cabling. With a fanless and therefore silent design, it is predestined for use in small and home offices. Basic layer-3 functions such as static routing and a DHCP server offer intelligent management with numerous security functions.

High performance on 10 ports
The LANCOM GS-3510XP is equipped with 4x 2.5G ports, 4x 1G Ethernet ports and 2x 10G SFP+ uplink ports. With a data throughput of 68 Gbps on the backplane, it offers full performance even under load. This switch is a high-performance basis for modern network infrastructures in small and home offices.
A high-performance basis for Wi-Fi 6
Thanks to 4 high-performance 2.5-Gigabit Ethernet ports, the LANCOM GS-3510XP is the ideal LAN-side basis for integrating the new Wi-Fi 6 standard into modern infrastructures. The increased data rates when using Wi-Fi 6 requires 2.5-Gigabit Ethernet, as the potential performance requirements exceed those of a 1-Gigabit Ethernet port. Given a sufficient PoE supply, this switch enables the operation of up to 4 Wi-Fi 6 access points or other network components with high performance requirements - without additional electrical installations.
Centralized power supply without additional electrical installations
The LANCOM GS-3510XP is a high-performance PoE switch that directly powers PoE devices connected to it; there is no need for additional power supply units or cabling. It supports the two Power-over-Ethernet standards, IEEE 802.3af and IEEE 802.3at (PoE+). It has high power-output reserves and an PoE budget of 130 watts makes it an effective power supply for PoE devices, even with its fanless and thus silent design.
Static routing for fast data exchange
The LANCOM GS-3510XP supports the basic layer-3 feature static routing and thus the shift of certain routing tasks from the router to the switch. Administrator-predefined network routes, through one or multiple network segments, enable fast data transfer especially in scenarios with high data volumes and relieve the router accordingly. Newly available router capacities can then additionally be used to manage external data traffic. As a result, the entire network efficiency is increased.
DHCP server functionality
As a DHCP server, the switch is able to independently and automatically assign IP addresses to clients. The LANCOM GS-3510XP supports this basic layer-3 function and thus takes over the IP management of the connected network.
Configurable access control
The LANCOM GS-3510XP excludes rogue clients from gaining unauthorized access to the network. This is ensured by secured access control on all ports as per IEEE 802.1X (port-based, single-based, multi-based, and MAC-based).
Secure remote management
Secure communication protocols such as SSH, SSL and SNMPv3 make the LANCOM GS-3510XP ideal for professional remote network management. The switch also support the TACACS+ protocol for authentication, authorization, and accounting. This optimized solution promises maximum security for multi-site network management and monitoring.
SD-LAN - days become minutes
The LANCOM GS-3510XP offers fast and easy network integration and automatic configuration assignment with the LANCOM Management Cloud - without manual configuration. In this way, even complex networking scenarios are easy to administer. SD-LAN eliminates the need for a single device configuration for holistic network orchestration. In addition, automatic VLAN assignment to the desired switch ports is possible. The configurations can be coordinated with each other across locations and network architectures, and at the same time rolled out or updated at the click of a mouse.
IPv6 and IPv4 support
Thanks to its dual-stack implementation, the LANCOM GS-3510XP operates in pure IPv4, pure IPv6 or in mixed networks. Applications such as SSL, SSH, Telnet or TFTP can continue to be operated on IPv6 networks. Supported IPv6 features includes stateless auto configuration, neighbor detection, and MLD snooping.

General

Device Type

Switch - 10 ports - L3 Lite - Managed

Enclosure Type

Rack-mountable 1U

Subtype

2.5 Gigabit Ethernet

Ports

4 x 10/100/1000 (PoE+) + 4 x 100/1000/2.5G (PoE+) + 2 x 10 Gigabit SFP+

Power Over Ethernet (PoE)

PoE+

PoE Budget

130 W

Performance

Throughput: 68 Gbps ¦ Throughput (64-byte packet size): 102 Mpps ¦ Latency: 4 µs

Capacity

Tagged VLANs: 4096 ¦ Active VLANs: 4000

MAC Address Table Size

16K entries

Jumbo Frame Support

10240 bytes

Routing Protocol

IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing

Remote Management Protocol

RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SMON, SSH, ICMP, IPv4, IPv6, TACACS+

Encryption Algorithm

SSL

Authentication Method

RADIUS, TACACS+

Features

VLAN support, port mirroring, store and forward, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, DHCP server, DHCP relay, Link Aggregation Control Protocol (LACP), Port Security, DHCP client, Energy Efficient Ethernet, Generic VLAN Registration Protocol (GVRP), IGMP proxy, IP source guard, Secure Copy (SCP), IGMP querier, Voice VLAN, Private VLAN Edge (PVE)

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz

Status Indicators

System, PoE, link/activity

Expansion / Connectivity

Interfaces

4 x 1000Base-T RJ-45 PoE+ ¦ 4 x 100/1000/2.5G RJ-45 PoE+ ¦ 2 x 10Gbit LAN SFP+ ¦ 1 x console RJ-45

Power

Power Device

Internal power supply

Installed Qty

Voltage Required

AC 120/230 V (50/60 Hz)

Power Consumption Operational

165 Watt

Power Consumption Stand by

15 Watt

Miscellaneous

Included Accessories

2 rack mount brackets

Cables Included

1 x serial cable - 1.5 m

Rack Mounting Kit

Included

Compliant Standards

EN55022, EN55024, EN 60950-1, FCC Part 15 A

Dimensions & Weight

Width

44 cm

Depth

22 cm

Height

24.2 cm

Weight

2.35 kg

Manufacturer Warranty

Service & Support

Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 90% (non-condensing)
