NETGEAR Insight WAX620 - Radio access point - 802.11a/b/g/n/ac/ax - 2.4 GHz, 5 GHz - wall / ceiling mountable

Qty:

Category (Netzwerktechnik)
Network Equipment
Network Equipment
OEM
WAX620-100EUS
EAN
0606449154511
SKU
140455 (140455)
Manufacturer
Netgear
Master carton
10.0000
Type
Access Point
Customs tariff number
85176200
UNSPSC
43222631
eClass
19-03-01-12
eClass V7
19-17-01-10
Dimensions (Girth)
245 x 245 x 85 (905)
Type
Access Point
Amount of ports
Other Amount of ports
Transmission rate
4Gbps

The WAX620 is a high-performance Wi-Fi 6 access point, ideal for small and medium sized businesses. The access point is a dual-band 4x4 design delivering up to 3.6Gbps total Wi-Fi throughput, supported by a 2.5Gbps Power-over-Ethernet port, an industry leader of performance and cost effectiveness in its product class.
The WAX620 supports the next-generation Wi-Fi 6 smart phones, IoT devices, and notebook computers, delivering up to 40% more throughput to each individual device in the 5GHz band and 100% more throughput in the 2.4GHz band, compared to the previous generation equivalent model; provides 4x the client device connection, allowing businesses to serve more customers with better speed and less congestion.
The WAX620 is ideal in high-density client device environments such as schools, hotels, restaurants and conference centers, and provides enterprise-grade Wi-Fi network security. With Insight management, WAX620 works seamlessly with your current NETGEAR Insight managed switches, Wi-Fi access points and network storage, and is compatible with previous generation Wi-Fi devices (Wi-Fi 5 802.11ac for example) and Wi-Fi access points.

General
Device Type
Radio access point
Ruggedized Design
Indoor
Width
20.57 cm
Depth
20.57 cm
Height
3.43 cm
Weight
783 g
Localisation
Europe
Networking
Form Factor
Wall / ceiling mountable
Connectivity Technology
Wireless
Line Coding Format
OFDM, OFDMA
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Spread Spectrum Method
OFDM, OFDMA
Remote Management Protocol
RADIUS
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum throughput (5 GHz): 2400 Mbps ¦ Maximum throughput (2.4 GHz): 1200 Mbps
Capacity
Maximum number of users: 256 ¦ Concurrent users: 75 ¦ SSIDs total: 8 ¦ Streams: 8
Wi-Fi Rating
AX3600
Status Indicators
Power, LAN, 2.4/5 GHz
Features
VLAN support, auto-uplink (auto MDI/MDI-X), MAC address filtering, Wireless Distribution System (WDS) support, Wi-Fi Multimedia (WMM) support, bandwidth control, LLDP support, Captive Portal, 802.1x authentication, Beamforming+, Transmit Power Control (TPC), band steering, WDS bridge, Backhaul Technology, 4x4 MU-MIMO technology, WDS PTMP (Point to Multipoint), WDS PTP (Point to Point), WDS repeater mode, Target Wait Time (TWT), BSS Coloring, Guest Network, Neighbor AP detection, Block SSID Broadcast
Encryption Algorithm
SSL, TLS, PEAP, TTLS, WPA, WPA2, WPA-Enterprise, WPA2-Enterprise, WPA3
Authentication Method
RADIUS, Extensible Authentication Protocol (EAP)
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
Antenna
Internal
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Expansion / Connectivity
Interfaces
1 x 1/2.5GBase-T (PoE+) - RJ-45
Miscellaneous
Included Accessories
Wall/ceiling mounting kit
Power
Power Over Ethernet (PoE) Supported
PoE+
Software / System Requirements
Software Included
NETGEAR Insight (1 year subscription)
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 5 years - response time: next business day ¦ Technical support - 90 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
