Zebra ZT231 Etikettendrucker Thermotransfer Rolle (11,4 cm) (ZT23142-T0E000FZ) (ZT23142T0E000FZ)
Zebra ZT231 Etikettendrucker Thermotransfer Rolle (11,4 cm) (ZT23142-T0E000FZ) (ZT23142T0E000FZ)

Zebra ZT231 Etikettendrucker Thermotransfer Rolle (11,4 cm) (ZT23142-T0E000FZ) (ZT23142T0E000FZ)

Zebra ZT231 - Label printer - thermal transfer - Roll (11.4 cm) - 203 dpi - up to 305 mm/sec - USB, LAN, serial, Bluetooth

Qty:

Category (Drucker, Scanner & Multifunktionsgeräte)
Printers & Accessories
Printers
OEM
ZT23142-T0E000FZ
EAN
4059312138525
SKU
139114 (139114)
Manufacturer
Zebra
Type
Label Printer
Customs tariff number
84433210
UNSPSC
44102405
eClass
19-02-90-02
eClass V7
19-14-01-90
Dimensions (Girth)
500 x 241 x 335 (1652)
Printing technology
Label Printer
Maximum printing resolution
203dpi

Demands are rising and timelines are shrinking. Do you have the printing capabilities to keep up - without interruption The ZT231 delivers the winning combination of the right features at the right price, along with the long-lasting quality you expect from Zebra. Fast print speeds, high-resolution print quality, large color touchscreen, future-forward design and more - all in one space-saving footprint. Plus, add optional capabilities like RFID, wireless connectivity and media handling features when you need them. But that's not all. Get built-in intelligence to make your work easier, and unmatched security so nothing stands in your way. That's how Zebra defines value.

  • Simple operation with smart features
    Reduce training time with the ZT231's easy-to-use 4.3" full-color touchscreen. See status at a glance, access wizards and helpful how-to videos and make changes with the touch of a finger or gloved hand. Seamlessly integrate the ZT231 into your existing network as it is backwards compatible and features Printer Emulations to replace other brands without having to change label formats or rewrite code.
  • Make it easy for your IT team
    Take advantage of Zebra's robust, ever growing Print DNA software suite for added capabilities. Easily configure, troubleshoot and manage your printers onsite or remotely via a web-based dashboard. Compare your printer security settings against best practices and adjust to match your preferences, while protecting your data from vulnerabilities.
  • The smart choice now and later
    The benefits of buying a ZT231 don't end at the point of purchase. Expand your printer's capabilities with field-installable upgrades when you need them. Add options such as a cutter or peeler, wireless connectivity or even UHF RFID encoding.
  • Get more done with greater visibility
    The ZT231 includes an adbanced architecture to process more jobs at once and evolve with emerging technologies. Onboard analytics and printhead element out detection help you plan maintenance in advance. And, the easy tool-less platen and print head removal makes maintenance easy.
  • Small footprint, big access
    To help you make the most of your workspace, Zebra has engineered the ZT231 with a space-saving, compact design and bi-fold door that reduces the height needed to open your printer. Take the trouble out of media loading with an intuitive design and color-coded cues. Adjustable sensors offer greater media flexibility and the large ribbon roll capacity lets you change media less frequently.
  • Connect your way
    Take advantage of a variety of standard connectivity options including USB, Serial, Ethernet and USB Host. Tap to pair and print with compatible mobile devices with the Print Touch tag (NFC). Add a second Ethernet port, 802.11ac or an Applicator port.
  • Get RFID without complication
    Incorporate UHF RFID printing and encoding for greater visibility and tracking. Get greater media flexibility and simple RFID calibration with Zebra's adaptive encoding technology that eliminates complex placement guidelines.
  • Unparalleled, peace-of-mind printer security
    Security risks are real and costly. Endpoints are becoming popular targets - including networked thermal printers. Shield yourself from cyber-attacks with Zebra's PrintSecure, part of Print DNA. Easily configure your printers via secure connections, identify vulnerabilities, block unauthorized access and detect events before they happen.

General
Printer Type
Label printer - thermal transfer - monochrome
Localisation
United Kingdom, Europe
Printer
Print Speed
Up to 305 mm/sec - B/W - 203 dpi - Roll (11.4 cm)
Built-in Devices
4.3 inch colour LCD touch screen
Connectivity Technology
Wireless
Interface
USB, LAN, serial, Bluetooth
Max Resolution (B&W)
203 dpi
Language Simulation
ZPL, ZPL II, EPL2, EPL
Fonts Included
1 x scalable ¦ 7 x bitmapped
Barcodes
Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Codabar, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, TLC39, Plessey, Code 128B, Code 128C, Code 128A, Standard 2 of 5, MSI, RSS-14
Printer Features
Zebra Programming Language (ZPL) support, Multi-level Element Energy Equalizer (E3)
RAM
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
Flash Memory
256 MB
Media Handling
Media Type
Continuous labels, die cut labels, black mark labels, notch
Max Media Size
Roll (11.4 cm)
Min Media Size (Custom)
19.4 mm
Max Media Size (Custom)
114 mm
Media Sizes
Roll (1.94 - 11.4 cm)
Max Printing Width
104 mm
Max Printing Length
3988 mm
Media Thickness Range
0.076 mm - 0.25 mm
Roll Maximum Outer Diameter
203 mm
Roll Core Diameter
76 mm, 25 mm
Media Feeders
1 x manual - 1 roll - Roll (11.4 cm)
Networking
Networking
Print server
Expansion / Connectivity
Connections
1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 ¦ 1 x LAN
Miscellaneous
Compliant Standards
FCC Class B certified, VCCI, BSMI, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15.247, CCC, KCC, FCC Part 15.209, S Mark, cTUVus, EN 62311, RCM, EN 300 328, BIS, RSS-247, IEC 62368-1, EN 301 893, EN 55035, UKCA
Power
Power Device
Power supply - internal
Voltage Required
AC 100-240 V
Frequency Required
50 - 60 Hz
Environmental Standards
ENERGY STAR
Yes
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 85% (non-condensing)
Dimensions & Weight
Width
24.1 cm
Depth
43.2 cm
Height
27.9 cm
Weight
9.1 kg
