Datalogic Gryphon I GM4500 - Kit - barcode scanner - portable - 2D imager - decoded - RF(433 MHz)

Qty:

Category (Scanner)
Printers & Accessories
Scanners
OEM
GM4500-BK-433K1
EAN
4060533233487
SKU
dtlsc000022 (103187)
Manufacturer
Datalogic
Type
Barcode scanner
Customs tariff number
84719000
UNSPSC
43211711
eClass
27-28-01-01
eClass V7
27-28-01-01
Dimensions (Girth)
260 x 170 x 120 (840)
Type
Barcode scanner
DIN format
Other DIN format

Designed with people in mind, the Gryphon 4500 series stands out with its elegant design, unchallenged ergonomics, and features an advanced sensor for outstanding performance.

  • Wireless charging
    An important technical innovation that the Gryphon 4500 wireless scanners achieve is the battery recharge through an inductive charging system, which enhances the reliability of the entire solution, lowering the total cost of ownership because it eliminates the need for contacts' cleaning and maintenance procedures.
  • Simple to use and deploy
    The Gryphon I 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes.

General
Type
Barcode scanner - portable
Colour
Black
Barcode
Interface Type
RF(433 MHz)
Minimum Bar Width
4 mil
Scan Element Type
2D imager
Sensor Resolution
1280 x 800
Light Source Wave Length
650 nm
Scan Mode
Single-pass
Skew (Degrees)
65
Pitch (Degrees)
65
Print Contrast Signal (PCS)
15%
Decode Capability
Code 39, GS1 DataBar, QR code, MaxiCode, Aztec code, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, China Post, Japanese Post, Kix (Netherlands) Post, MacroPDF417, RM4SCC, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked
TTL Decoding
Decoded
Connectivity Technology
Wireless
OK Notification
Beeper, LED indicator
Expansion / Connectivity
Interfaces
1 x USB
Miscellaneous
Cables Included
USB cable
Compliant Standards
RoHS, IEC 60529 IP52
Power
Power Device
Barcode scanner charging stand
Battery
1 x Lithium Ion
Dimensions & Weight
Width
6.8 cm
Depth
16.6 cm
Height
10.9 cm
Weight
235 g
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95% (non-condensing)
Drop Specification
1.8 m to concrete
