Datalogic QuickScan QD2430 - Barcode scanner - handheld - 2D imager - USB

Qty:

Category (Scanner)
Printers & Accessories
Scanners
OEM
QD2430-BKK1B
EAN
5712505141496
SKU
dtlsc000030 (118615)
Manufacturer
Datalogic
Type
Barcode scanner
Model
QuickScan QD2430
Customs tariff number
84719000
UNSPSC
43211711
eClass
27-28-01-01
eClass V7
27-28-01-01
Type
Barcode scanner
DIN format
Other DIN format

The popularity of 2D bar codes has spread across all market segments of the data capture industry. Now, with more affordable pricing and virtually no drawbacks with area imaging technology, 2D bar code readers are in high demand with features such as reading from mobile phone displays or in planning ahead for future 2D codes and imaging needs.
The QuickScan QD2400 2D imager was specifically created to address the needs of retailers and meet the market demand with outstanding omnidirectional reading performance on virtually all codes at an affordable price. Elegant design details are incorporated into a smaller, balanced lightweight enclosure without sacrificing Datalogic's well-known durability.
Ideally suited for applications at the point-of-sale (POS), the QuickScan QD2400 imager features a new illumination and aiming system developed with the unique intent to reduce visual stress of the operator during the daily scanning activities. It consists of a soft, dark red illumination combined with two blue LED triangles pointing at the targeted bar code. The result is a precise aiming system which contributes to low eye fatigue, yet still allows top operator efficiency.
The QuickScan QD2400 imager reads typical printed linear bar codes as well as complex 2D bar codes displayed on the screen of a mobile device or loyalty cards. The QD2400 imager provides a fast, reliable scan from an elegant and robust 2D imager.
Imaging technology meets or exceeds the productivity compared to laser scanners and provides the additional advantages of a lower cost-of-ownership and greater product reliability over the long term.

General
Type
Barcode scanner - handheld
Colour
Black
Barcode
Interface Type
USB
Scan Element Type
2D imager - Red LED
Light Source Wave Length
650 nm
Scan Mode
Single-pass
Decode Capability
Code 39, QR code, Aztec code, MicroPDF417, French Pharmacode, Postnet, PDF417, Data Matrix, PLANET, Australian Post, Canadian Post, China Post, Japanese Post, Kix (Netherlands) Post, Royal Mail, 4-State postal code, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, Swedish Post, GS1 DataBar Composites, GS1 DataBar Stacked, Portuguese Post
Features
Datalogic STAR Cordless System
Expansion / Connectivity
Interfaces
1 x USB - Type A
Miscellaneous
Compliant Standards
IEC 60950, UL 60950
Dimensions & Weight
Width
16.3 cm
Depth
9.1 cm
Height
4.1 cm
Weight
145 g
Manufacturer Warranty
Service & Support
5-year warranty
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95% (non-condensing)
