Datalogic QuickScan 2500 Series QW2520 Kit (QW2520-BKK1S) (QW2520BKK1S)
Datalogic QuickScan 2500 Series QW2520 Kit (QW2520-BKK1S) (QW2520BKK1S)

Datalogic QuickScan 2500 Series QW2520 Kit (QW2520-BKK1S) (QW2520BKK1S)

Datalogic QuickScan 2500 Series QW2520 - Kit - barcode scanner - handheld - 2D imager - decoded - USB


Category (Drucker, Scanner & Multifunktionsgeräte)
Printers & Accessories
138234 (138234)
Barcode scanner
Customs tariff number
eClass V7
Dimensions (Girth)
220 x 185 x 100 (790)
Barcode scanner
DIN format
Other DIN format

The QuickScan 2500 imager from Datalogic is an entry level 2D corded handheld scanner that punches well above its weight when it comes to performance. It is the robust and reliable companion in the retail sector for your POS checkout, built for many years of continued service. It effortlessly reads a full range of barcodes, be they damaged, hard to read, or poorly printed. In addition, the QuickScan 2500 imager is optimized to seamlessly read through plexiglass barriers. All of these must-have benefits are available at an incredibly affordable price, making the QuickScan QuickScan 2500 imager the desirable addition to the Datalogic family of renowned handheld barcode scanners.

  • Improve performance with user friendly feedback
    When using the QuickScan 2500 imager, you want a low-cost device with top guaranteed scanning performance and a reliable read every time, period. You want an easy to aim device that gives clear audible, tactile and visual feedback on each read, good or bad. You want a device that sits comfortably in your hand and never gives you fatigue, no matter how long your working shift. The QuickScan 2500 imager does not fail, even when continually used for long periods of time and provides plenty of freedom of movement with high quality cables that are robust enough to withstand constant abuse. Any type of barcode - 1D, 2D, postal codes, stacked or composite barcodes, dotcodes, and digital watermark codes - the QuickScan 2500 imager has you covered.
  • Connect, configure, use
    As well as being the very affordable and easy to use handheld scanning solution for your business, the QuickScan 2500 imager is extremely easy to setup. It will give you the best fit for your store environment. The simple and seamless configuration of the scanner with connectivity to all manner of hosts, makes this the only solution you will need for your business. It is well built and will comfortably survive 5 ft drops and over 10 million trigger presses. The adjustable brightness of the light source makes it comfortable to suit most people's eyes. With Motionix technology, the imager is ready for action as soon as it is picked up. All in all, you have at your fingertips the perfect device for scanning all your goods.
  • Perform
    The QuickScan 2500 imager boasts a very rich feature set for out-of-the-box capabilities. The 1 MP optics provide best-in-class scanning and depth of field for all your applications. No need to worry about scanning orientation as it is omnidirectional. It will seamlessly read codes displayed on smartphone screens, making promotions and coupons easy to manage. The imager is equipped with an easy to see aiming system that consists of two blue triangles, providing full guidance with extreme precision. This makes it easy for the staff to target the right code to read, and the patented Green Spot technology from Datalogic is clearly projected as a visual indicator upon each successful read.
  • Don't underestimate the versatility
    The QuickScan 2500 imager is best known in retail applications. However, this highly versatile reader is equally comfortable in commercial services, healthcare, hospitality, government, and light manufacturing uses. There are enough accessories and software configurations to make sure you can simply create a customized solution for your business. When compared to similar entry-level handheld scanners on the market, the QuickScan 2500 imager represents the best value and versatility of products available today. All of this is neatly packaged in an optimized form factor with a high-quality finish and feel. This long-lasting and affordable investment will consistently deliver the top performance compared to other similar handheld scanners on the market.

Barcode scanner - handheld
Interface Type
Minimum Bar Width
3 mil
Scan Element Type
2D imager - Red LED
Sensor Resolution
640 x 480
Light Source Wave Length
624 nm
Scan Mode
Max Working Distance
40 cm
Skew (Degrees)
Pitch (Degrees)
Print Contrast Signal (PCS)
Decode Capability
EAN/JAN, Code 93, Code 39, Code 49, GS1 DataBar, QR code, MaxiCode, Aztec code, MicroPDF417, Postnet, Data Matrix, PLANET, Australian Post, British Post, China Post, Japanese Post, Kix (Netherlands) Post, Royal Mail, Micro QR code, China Han Xin Code, Intelligent Mail Barcode, UPC A Composite, UPC E Composite, DotCode
TTL Decoding
Connectivity Technology
OK Notification
Beeper, LED indicator
Green Spot technology, Remote Systems Management
Expansion / Connectivity
1 x USB - Type A
Included Accessories
Cables Included
USB cable - external
Compliant Standards
RoHS, IP52
Electric Current Required
90 mA (standby), 400 mA (typical)
Software Included
Datalogic Aladdin, OPOS/JavaPOS Drivers
Dimensions & Weight
6.8 cm
12.6 cm
14.8 cm
145 g
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95% (non-condensing)
Drop Specification
1.5 m to concrete
