Datalogic Gryphon I GD4132 - Barcode scanner - handheld - linear imager - 325 scan / sec - decoded - keyboard wedge, RS-232, USB, wand

Qty:

Category (Scanner)
Printers & Accessories
Scanners
OEM
GD4132-BKK1
EAN
4062621250222
SKU
dtlsc000012 (103195)
Manufacturer
Datalogic
Type
Barcode scanner
Customs tariff number
84719000
UNSPSC
43211711
eClass
27-28-01-01
eClass V7
27-28-01-01
Dimensions (Girth)
220 x 100 x 75 (570)
Type
Barcode scanner
DIN format
Other DIN format

The Gryphon 4100 series readers eliminate the need for cables that limit operator movement and create safety concerns in the workplace. Datalogic's unique 2-position cradle provides multiple features for the user.

General
Type
Barcode scanner - handheld
Colour
Black
Barcode
Interface Type
Keyboard wedge, RS-232, USB, wand
Minimum Bar Width
3 mil
Scan Element Type
Linear imager
Light Source Wave Length
630-670 nm
Scan Mode
Single-pass
Scan Speed
325 scan / sec
Skew (Degrees)
65
Pitch (Degrees)
65
Print Contrast Signal (PCS)
15%
Decode Capability
GS1 DataBar, China Post, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked
TTL Decoding
Decoded
Connectivity Technology
Wired
OK Notification
Beeper, LED indicator
Expansion / Connectivity
Interfaces
1 x USB ¦ 1 x wand ¦ 1 x RS-232 ¦ 1 x keyboard wedge
Miscellaneous
Cables Included
1 x USB cable - external - 2 m
Compliant Standards
IP52, China RoHS, EU RoHS, EN 60825-1 Class 1
Power
Electric Current Required
245 mA (operating), 120 mA (standby)
Dimensions & Weight
Width
7.1 cm
Depth
10 cm
Height
18.1 cm
Weight
169 g
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
55 °C
Humidity Range Operating
0 - 90%
