Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)
Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)
Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)
Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)
Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)
Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)

Honeywell Barcode Scanner Genesis 7580 (MK7580-30B38-02-A) (MK758030B3802A)

Honeywell Genesis 7580 - Barcode scanner - desktop - decoded - USB

Qty:

Category (Scanner)
Printers & Accessories
Scanners
OEM
MK7580-30B38-02-A
EAN
8437014324358
SKU
honsc000033 (105062)
Manufacturer
Honeywell
Master carton
1
Type
Barcode scanner
Model
Genesis 7580
Customs tariff number
84719000
UNSPSC
43211711
eClass
27-28-01-01
eClass V7
27-28-01-01
Dimensions (Girth)
195 x 125 x 110 (665)
Type
Barcode scanner
DIN format
A1

Honeywell's Genesis 7580, the world's first presentation area-imaging scanner engineered to decode all standard 1D, PDF and 2D codes, provides enhanced productivity and revolutionary imaging technology in an elegant, yet durable design.
The 7580 is redefining industry standards for imaging solutions. Breakthrough performance and a versatile form factor make this product suitable for environments ranging from manufacturing to healthcare to retail POS.
Patented CodeGate technology along with an activation button support menu-scanning and other targeted-scanning applications. Unlike other scanners with multiple on-board interfaces, the 7580 has four dedicated memory banks - each one capable of storing full configuration settings for RS232, keyboard wedge, USB and 46xx RS485 interfaces.
Automatic cable detection and configuration simplifies migration to a new interface by eliminating the need to scan programming bar codes. Three additional patented technologies augment the 7580's unmatched feature set. Shielded LEDs minimize the intense flashing common among other area imagers. CodeSelect allows the 7580 to capture up to seven bar codes in a single flash and output data in any predetermined order. TotalFreedom expands scanner functionality by allowing formatting, parsing and decoding plug-ins to be loaded directly to the 7580 instead of the host system.

General
Type
Barcode scanner - desktop
Colour
Black
Localisation
United States
Barcode
Interface Type
USB
Minimum Bar Width
4 mil
Scan Element Type
Red LED
Light Source Wave Length
645 nm
Scan Mode
Fixed projection
Skew (Degrees)
75
Pitch (Degrees)
70
Print Contrast Signal (PCS)
20%
Decode Capability
EAN/JAN, Code 93, Matrix 2 of 5, Code 39, NW-7, GS1 DataBar, QR code, MaxiCode, Aztec code, Telepen, Code 32, MicroPDF417, Codabar, Code 128, Code 11, Code 2 of 5, UPC, Interleaved 2 of 5, Postnet, PDF417, MSI-Plessey, Data Matrix, PLANET, Australian Post, British Post, Canadian Post, China Post, Japanese Post, Kix (Netherlands) Post, Trioptic Code, EAN-UCC Composite, OCR-A, OCR-B, MICR E-13B, Micro QR code, 4-State postal code, Code 93i, China Han Xin Code
TTL Decoding
Decoded
Connectivity Technology
Wired
OK Notification
LED indicator
Features
Image capturing, Reduced Space Symbology (RSS), TotalFreedom, CodeSelect, CodeGate
Expansion / Connectivity
Interfaces
1 x USB - Type A
Miscellaneous
Cables Included
1 x USB cable - 2.9 m
Compliant Standards
ICES-003, EN55022 Class B, FCC Part 15, RoHS, WEEE, IEC 60825-1, cULus, EN 60825-1
Power
Power Device
Power adapter - external
Power Consumption Operational
2 Watt
Electric Current Required
167 mA (operating), 109 mA (standby)
Software
Software Included
MasterMind
Dimensions & Weight
Width
8.3 cm
Depth
8 cm
Height
15 cm
Weight
340 g
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 95% (non-condensing)
Drop Specification
1.5 m
