Lenovo ThinkPad Ultra Docking Station - Docking station - VGA, HDMI, 2 x DP - 135 Watt - Korea, Europe - for ThinkPad L490; L590; P43s; P53s; T49X; X1 Carbon (7th Gen); X1 Yoga (4th Gen); X39X

Qty:

Category (Zubehör Notebook)
PC Systems
Notebook Accessories
OEM
40AJ0135EU
EAN
0192076019854
SKU
lenac000025 (109237)
Manufacturer
Lenovo
Type
Charging / Docking station
Line
Lenovo ThinkPad
Color
Black
Customs tariff number
84718000
UNSPSC
43211602
eClass
19-01-92-01
eClass V7
19-01-92-01
Dimensions (Girth)
412 x 220 x 86 (1024)
Type
Charging / Docking station

Lenovo ThinkPad Ultra Docking Station provides excellent docking experience for Large Enterprise ThinkPad customers. The innovative side connector, designed exclusively for ThinkPad notebooks, provides a driver-free way to connect conveniently and securely to a range of USB accessories and external displays, while rapid charging support and a mirrored power button make going mobile even easier. Designed for large enterprise environments, ThinkPad. Docking Stations support PXE book, Wake-on-LAN, and MAC address pass-through, simplifying asset management for IT managers. Painstakingly crafted and extensively tested, ThinkPad Docking Stations provide a seamless docking experience for professionals.

General
Product Type
Docking station
Width
37.8 cm
Depth
15.9 cm
Height
5.41 cm
Weight
810 g
Localisation
Korea, Europe
Video
Max Resolution Details
4096 x 2160 - 60 Hz (DisplayPort only) ¦ 4096 x 2160 - 60 Hz (HDMI only) ¦ 2048 x 1536 - 85 Hz (VGA only) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort1 and DisplayPort2 simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (DisplayPort and VGA simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (HDMI and VGA simultaneously) ¦ 4096 x 2160@60Hz, 1920 x 1080@60Hz, 1920 x 1080@60Hz (DisplayPort1 and DisplayPort2 and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz, 2048 x 1536@85Hz (DisplayPort and HDMI and VGA simultaneously)
Expansion / Connectivity
Interfaces
1 x USB 3.1 Gen 2 with Always-on charging ¦ 3 x USB 3.1 Gen 2 ¦ 2 x USB-C ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x audio - headphones/microphone - mini-phone stereo 3.5 mm ¦ 1 x docking / port replicator
Miscellaneous
Included Accessories
2 x security keys
Features
Security lock slot (cable lock sold separately), wake on LAN, Preboot Execution Environment (PXE) support, MAC address pass-through
Compliant Standards
UL, cUL, NOM, FCC, ICES
Power
Power Device
Power adapter
Power Provided
135 Watt
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight (Shipping)
Shipping Width
42.2 cm
Shipping Depth
20 cm
Shipping Height
8.6 cm
Shipping Weight
2 kg
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Compatibility Information
Designed For
Lenovo ThinkPad A285 20MW, 20MX ¦ Lenovo ThinkPad A485 ¦ Lenovo ThinkPad E490s 20NG ¦ Lenovo ThinkPad L13 20R4 ¦ Lenovo ThinkPad L13 Yoga 20R5, 20R6 ¦ Lenovo ThinkPad L14 Gen 1 20U1, 20U2 ¦ Lenovo ThinkPad L15 Gen 1 20U3 ¦ Lenovo ThinkPad L480 ¦ Lenovo ThinkPad L490 ¦ Lenovo ThinkPad L580 ¦ Lenovo ThinkPad L590 ¦ Lenovo ThinkPad P14s Gen 1 20S4, 20S5 ¦ Lenovo ThinkPad P43s 20RH, 20RJ ¦ Lenovo ThinkPad P52s ¦ Lenovo ThinkPad P53s ¦ Lenovo ThinkPad T14 Gen 1 20S0, 20S2 ¦ Lenovo ThinkPad T14s Gen 1 20T0 ¦ Lenovo ThinkPad T480 ¦ Lenovo ThinkPad T480s ¦ Lenovo ThinkPad T490 20N2, 20Q9, 20QH, 20RX, 20RY ¦ Lenovo ThinkPad T490s 20NX ¦ Lenovo ThinkPad T495 ¦ Lenovo ThinkPad T495s ¦ Lenovo ThinkPad T580 ¦ Lenovo ThinkPad T590 20N4 ¦ Lenovo ThinkPad X1 Carbon (6th Gen) 20KG, 20KH ¦ Lenovo ThinkPad X1 Carbon (7th Gen) ¦ Lenovo ThinkPad X1 Carbon Gen 8 20UA ¦ Lenovo ThinkPad X1 Yoga (4th Gen) ¦ Lenovo ThinkPad X1 Yoga Gen 5 20UC ¦ Lenovo ThinkPad X13 Yoga Gen 1 20SX, 20SY ¦ Lenovo ThinkPad X390 20Q0, 20Q1, 20SC, 20SD ¦ Lenovo ThinkPad X390 Yoga ¦ Lenovo ThinkPad X395
